Small Metal Enclosure Box

Small Metal Enclosure Box

Zhongfeiya Enclosures is the leader manufacturer in steel electrical enclosure,stainless steel electrical enclosures,weatherproof electrical junction box,wall mount electrical box,recessed wall box with cover,electrical boxes in fire rated walls,IP rated electrical box and NEMA rated enclosure.Our electric enclosures are impact resistance and eco-friendly.
ISO Certified.
Various Sizes Available.
1-2 Days Sample when stock are available
3 days of customized sample after receiving the 2D or 3D drawings.
Superior Customer Service.

Features & Specifications
Protection: Complies with IP66 IK10, NEMA 4x (Independent accredited test laboratory).

Standard: IEC 62208, IEC/EN/AS60529, (UL 508A Optional), RoHS

Conforming and certified to IEC 62208 – ‘Empty enclosures for low voltage switch gear and control gear assemblies.

Material:
– Body: 1.5mm Grade 316/316L Stainless Steel (Optional 304)

– Door: 1.5mm Grade 316/316L Stainless Steel (Optional 304)
– Device Mounting Plate: 1.5mm Galvanized Steel Sheet
– Seal: Polyurethane

Surface Finish:0.4 micron

Enclosure Body:
The robust monoblock body is fabricated using 1.5mm Grade 316/316L Stainless Steel and grade 304 is also available. Flat face sealing surfaces are provided to increase seal life. Pre-fitted blind nut sets are incorporated to accommodate mounts and accessory fasteners to eliminate drilling and retain IP rating. Integral device plate mounts and M6 earth studs are provided. Cutting, pressing and full continuous seam welding using precision automated manufacturing equipment ensures accuracy and consistent high quality.

Enclosure Door:
The robust surface mounted door is fabricated using 1.5mm Grade 316/316L Stainless Steel and incorporates concealed removable hinges with captive pins (Grade 304 is also available). The door is designed for a 110° opening. Each door contains cable management rails, an M6 earth stud and a high quality machine-applied foamed in place (FIP) Polyurethane seal. Two internal cable management rails can be removed to provide additional space for equipment, duct and door mounted control components.

Enclosure Seal:
A high quality machine-applied full perimeter UL listed Polyurethane seal foamed in place (FIP) provides excellent sealing over a long life. Temperature resistance -40°C to 80°C (160°C short term loading).

Enclosure Lock:Grade 316 Stainless Steel 8mm square drive quarter turn lock with key. A full range of locking solutions are available upon request. Device Mounting Plate:The device mounting plate is galvanized steel sheet. It is pressed to provide strength and is pr-fitted into the enclosure.

FAQ

Q1: ARE YOU A MANUFACTURER OR TRADING COMPANY ?

A: We are a leading manufacturer of QUALITY INDUSTRIAL PLUG AND SOCKET with more than 10 years experience.

Q2: CAN I GET FREE SAMPLE BEFORE ORDER?

A: Free Sample is available, but the sample freight should be pay by you.The cost of sample will be refund after further order.

Q3. DO YOU HAVE ANY MOQ FOR TRIAL ORDER?

A: No MOQ requirement.

Q4: WHAT'S YOUR TERMS OF PAYMENT?

A: 30% T/T in advance,balance before shipment.

Q5: CAN YOU CUSTOMIZE MY PRODUCTS OR PUT MY LOGO ON YOUR PRODUCTS?

A: Yes, we offer OEM and ODM services. Please inform us formally before production.

Q6: WHAT'S THE LEAD TIME ?

A: Usually, sample orders takes 1-2 business days. For mass production, it largely depends on order quantity. Please let us know your requirement, we will do our best to deliver the goods in time.

Q7: WHAT ABOUT THE SHIPPING METHODS?

A: For small or urgent orders, door-to door courier delivery like DHL, UPS, FedEx or TNT is recommended; for large orders, sea or air transportation is recommended.
