Outdoor Wall Mount IP66 SMC Electrical Enclosures
Outdoor Wall Mount IP66 SMC Electrical Enclosures Waterproof Fiberglass Junction Box
SMC junction box 800*600*300
SMC junction box prevents people from the peril that comes from the dangerous wires exposed and also the wires itself from the hazardous weather conditions.
These boxes,supplied by ZFY TECH are constructed with shockproof and rustproof materials guaranteed of absolute waterproof capability that can stand a high heat distortion temperature of about 200°C per IS:10192. Needed for offices and home precautions, they are designed to protect wiring junctions with their rot, termite, and pilferage proof fire retardant materials when connecting to the main source of power supply.
It has a pole mounting arrangement where you can enter cables from either bottom or sides and it is tamper proof and restricts unauthorized tapping; hence, it is beneficial for public and residential buildings and a practical tool to guarantee safety for all. Since there are a lot of instances where fires, electrocution, accidents and also deaths are already reported due to current leakage, a SMC junction box is a great device to use as a preventive measure.
| IP66 Waterproof SMC box | Dimension: 800*600*300 mm |
| Open Type | Door type with lock |
| Seal ring material | Poly amino acid |
| Protection Rating | IP65/IP66 |
| Color | Waterproof Hinged Plastic Box |
| Machanical Impact | IK08 |
| Accessories | Waterproof cable gland,terminals,honeycomb plate etc |
| Holes | Customized |
| Feature | Anti-corrosion,insulating,light and easy to operate |
| Application | Airport,subway station,button box,signal,relay and sensor etc |
| Item | Size |
| SMC-302514 | 300*250*140 |
| SMC-403020 | 400*300*200 |
| SMC-404020 | 400*400*200 |
| SMC-504020 | 500*400*200 |
| SMC-604023 | 600*400*230 |
| SMC-605023 | 600*500*230 |
| SMC-806030 | 800*600*300 |
Features:
Fiberglass Reinforced Polyester
The electrical box features fiberglass reinforced polyester construction with high toughness, resistance to pressure, corrosion, and rust. The enclosure is impervious to dents.
Thickened Dust Lock
The inner lock core uses metal to prevent damage caused by excessive force. The durable and reliable cabinet door lock is applied for a convenient opening with longer service life.
High Strength Hinge
The electrical box adopts reinforced hinges, which will not be damaged if it is repeatedly opened and closed, and ensure that the box door is not easily broken by extrusion.
Rubber Sealing Strip
The sealing rubber strip is close to the box door with strong sealing performance to prevent dust and raindrops from dripping into the box and causing electricity leakage.
IP 65 & Protective
The IP65 waterproof design effectively blocks splashing water, rain, dust, snow, oil into the electrical enclosure and causing damage. It keeps your equipment well-protected in harsh environments.
Effortless to Install
Galvanized back plate can be removed and installed simply with high hardness and oxidation resistance. There are t-nut mounting slots for DIN guide rails and equipment mounting plates.
