Name: Single Door Floor Standing Enclosure
Brand: Zhongfeiya Tech
SKU: 161712555

Single Door Floor Standing Enclosure

Type:	Free Standing Electrical Enclosures	Place of Origin:	China
Frame:	Full Welded	Brand Name:	Zhongfeiya Tech
Size:	From 1600x600x300mm To 2200x1200x800mm	Certification:	TUV/ SGS

A floor standing electrical enclosure is a large free-standing storage space used to house and protect equipment, usually electronic equipment. The range of floor standing electrical enclosure includes single-door or double-door cabinets. Floor mount electrical enclosures consist of a large unit, usually made of metal, which can accommodate several electrical equipment and other instrument racks. Floor-standing enclosures have a widely range of application in various industries from electrical to automation to provide protection against dust and liquids that may damage the contents.

How floor standing enclosure work?

As the floor standing enclosure is close to the device, it takes up minimal additional space. They are usually equipped with a locking system to ensure that the door cannot be accidentally opened. They usually also have the capacity of enclosure accessories, such as handles, fans, and mounting panels. Most floor-standing enclosures have an IP rating to protect against dust and liquids. IP55 is the most common, it enables the contents of the enclosure to remain in complete working condition in the event of harmful dust or liquid spray.

Types of floor-standing enclosures

The main difference between floor-standing cabinets is their size, which depends on the size of the equipment they need to accommodate. They are also made of different materials, which affects their strength and whether the device can be seen from the outside. They can have one or two doors.
electrical enclosure box

Floor Standing Enclosure, Single Door, Mild Steel, IP66

Height: 1200, 1400, 1600, 1800 or 2000mm

Width: 600, 800 or 1000mm

Depth: 300, 400 or 500mm

Customized dimensions are accepted

Single door full welded free standing stainless steel industrial enclosure

Materials: AISI 304 pre-grained stainless steel/AISI 316L

Body and removable rear panel: 1.5mm

Door: 2mm

Bottom plate: 1.5mm

Mounting plate: 2.7mm galvanized steel

Body: 1-piece enclosure

Integrated depth profiles with hole pattern allowing mountingplate adjustable in depth

Door: surface-mounted with 4 hinge, including door frame with25mm hole pattern and earthing studs

Rear panel: fitted by M6 screws

Standard facilities for rear door mounting

Lock: external 4-point locking system

Standard fitted double-bit 3mm insert

Single door full welded free standing stainless steel industrial enclosure can be exchanged for standard range of inserts, Euro-cylinder and swing handle

Bottom plates for floor standing electrical enclosures: 1-piece bottom plate with injected polyurethane gasket to ensure maximum sealing

Mounting plate: double folded and slides into position

Adjustable in depth by steps of 25mm

Earthing: door equipped with separate welded earthing studs and earthing to frame can be accomplished

Finish: per-grained stainless steel

Finish of floor standing electrical enclosures

enclosure finish is rAL 7035 textured light-gray polyester powder paint with black accent color of rAL 9005 textured polyester powder paint

Material of floor standing electrical enclosures:Outlet enclosure: sheet steel 1.5mm

Door: 2.0mm

Mounting plate:2.0mm galvanized zinc

Finish:gray polyester powder paint inside and out

Color: RAL7032 or RAL7035

Floor standing electrical enclosures can be supplied include

Enclosure and door,plinth,mounting plate,3-point lock system,gland plate,sealing gasket and accessories

Reference	Size
ZFY-A 146/30	1400	600	300
ZFY-A 146/40	1400	600	400
ZFY-A 148/30	1400	800	300
ZFY-A 148/40	1400	800	400
ZFY-A 1410/30	1400	1000	300
ZFY-A 1410/40	1400	1000	400
ZFY-A 1412/40	1400	1200	400
ZFY-A 166/30	1600	600	300
ZFY-A 166/40	1600	600	400
ZFY-A 168/30	1600	800	300
ZFY-A 168/40	1600	800	400
ZFY-A 1610/30	1600	1000	300
ZFY-A 1610/40	1600	1000	400
ZFY-A 1612/30	1600	1200	300
ZFY-A 1612/40	1600	1200	400
ZFY-A 186/30	1800	600	300
ZFY-A 186/40	1800	600	400
ZFY-A 188/30	1800	800	300
ZFY-A 188/40	1800	800	400
ZFY-A 1810/30	1800	1000	300
ZFY-A 206/30	2000	600	300
ZFY-A 206/40	2000	600	400
ZFY-A 208/30	2000	800	300
ZFY-A 208/40	2000	800	400
ZFY-A 2010/30	2000	1000	300

Manufacturing Process of Single Floor Standing Electrical Enclosures

Welding

Zhongfeiya Tech adopts welding robots, automated mechanical equipment used for welding operations. Welding robots can realize production automation and effectively help Zhongfeiya Tech to achieve transformation and upgrading.Offer good price with good quality metal electric enclosures.

spot welding,block welding,full welding,arc welding,Pressure riveting,Pull rivet.

Sealing

Processional custom IP enclosure manufacturer

Formed In Place Foam Gasket Sealing- Electric Enclosures

Punching, stamping

Zhongfeiya Tech has a wide range of equipment 25-200Tthat can support all common punching process.

Professional Manufacturing to custom perfect electrical enclosure.

Zhongfeiya Tech has the capability to tailor made unique electrical enclosure for your project.The precision of metal electrical enclosure is +/- 1mm tolerance for overall cabinet size.And Zhongfeiya Tech can offer standard configuration such as gland plate, radiating fan, fluorescent lamp, lamp switch, ground connections, PU foaming seals etc.

Surface treatment

Polishing , chrome painting, stain chroming, matting ,powder coating

Assembly

we can help assembly simple electronic accessories, parts as customer requirements

stainless steel enclosures manufacturer
