Ways to wire the distribution box to various electrical equipment
When decorating the circuit in our house, we must consider a problem, that is, how to arrange the pipeline from the distribution box to each power point, that is, how to arrange the circuit. In fact, there are many methods here. There are two most commonly used methods: one is the two-point one-line connection principle, and the other is the horizontal and vertical principle.
Ways to lay out lines from distribution boxes to various electrical equipment
The first step is to arrange the line pipe from the lower opening of the switch in the distribution box, and arrange the line pipe along the wall to the ceiling or to the ground. At this time, the wall needs to be slotted and slotted. The depth of the slot is about two centimeters, and the width of the slot is five centimeters on each side of the pipe.
The second step is to then arrange the pipes along the ground or the roof to our electricity points.
When laying pipes on the ground, generally speaking, you don’t need to slot them and arrange them directly on the ground, because they can be completely covered when tiles are to be laid later. When arranging the pipes on the roof, arrange them directly along the roof. This arrangement requires a suspended ceiling in the future. If the ceiling is not suspended, the pipes can only be arranged along the ground.
The third step is to then arrange the pipes along the wall up or down the ceiling.
Then the line pipes arranged above, when they reach the wall, arrange them upwards or follow the line pipes on the top plate downwards. At this time, it can be arranged to the position of the switch or the bottom box of the socket. At this time, slotting is also performed on the wall.
A brief introduction to the number of lines and pipes arranged by the household distribution box to the electric potential
The first step is to divide the electrical circuits in the home. For example, the most common way to divide the circuit is as follows: one circuit for lighting, one circuit for ordinary sockets, one circuit for wall-mounted air conditioners, one circuit for cabinet air conditioners, one circuit for kitchens, and one circuit for toilets. This adds up to the basics. There are about eight circuits.
The second step is to arrange the line pipe, it is recommended to spring the line in advance.
Each circuit requires a separate line tube, that is to say, eight line tubes are laid out from the lower port of the distribution box. The same is true for other ways of dividing loops. In addition to the lighting circuit, there are three wires that should be worn in each circuit, that is, a live wire, a neutral wire and a ground wire.
Analysis on the Layout Principles of Family Circuit Line Tubes
The first layout principle of household line pipes is the horizontal and vertical pipeline layout principles used by many decoration companies now. This way of arranging pipelines looks very beautiful and tidy, and the wiring and pipes are very regular. One of the biggest advantages of this method is to plan the line's unknown direction in advance, which can avoid damage to the line pipes placed under the ground or inside the wall during the future decoration.
The second principle of non-disclosure of home circuit cash is two points and one line.
The two-point-one-line layout method is very simple, that is, go straight from the distribution box and arrange the line pipes to the points where we need electricity.
Comparison of horizontal and vertical wiring and two-point one-line wiring
The advantage of the horizontal, horizontal and vertical line layout is that it is beautiful, and it can prevent damage to the line pipe in the later period. The shortcomings are also obvious: the first point is that it is very difficult to thread and change later because there are many dead ends. The second point is that the cost will be much higher.
The advantage of the two-point one-wire wiring method is that it saves a lot of costs, and it is very convenient to replace the wires in the future.
The disadvantage is that it is not beautiful, and it does not have a good protective effect on the hole punching on the ground and the wall of the future decoration.
Concluding:
As for how to route the equipment from the distribution box to each point, we think it is to separate the dropped wires first, and then arrange the pipelines.
